P2P Network Video Recorder

Product Name:P2P Network Video Recorder
Type:Network Video Recorder
Technology:Infrared camera
Sample:available
MOQ:1pcs
Warranty:1 year
OEM Service:YES
Shipping:DHL,Fedex, UPS, TNT Fast Express
Payment:LC,TT,West Union,Paypal...

Product Advantages



Specification

Model No.:

XVR-7504-L

XVR-7508-L

System

Operation System

Embedded LINUX

Pentaplex function

Live monitoring, recording, playback, backup & remote access

Control Mode

Front panel, USB/Wireless mouse, IR remote, Network

Video

Input

Hybrid input(Mix freely):
TVI / AHD / CVI (720/960/1080P)+ IP (720/960/1080P)
+ CVBS(960H)

Hybrid input(Mix freely):
TVI / AHD / CVI (720/960/1080P)+ IP (720/960/1080P)
+ CVBS(960H)

Standard

PAL    /    NTSC

Frame Rate

Live Preview:  PAL: 1~25fps; NTSC: 1~30fps

Output

1 CVBS, BNC

1 HDMI, 1920×1080,1280×1024,1366×768,1280×720,1024×768 Resolution

1 VGA, 1920×1080,1280×1024,1366×768,1280×720,1024×768  Resolution

UTC

Control AHD/TVI Camera  & PTZ Spped Dome camera  via DVR by Coaxial Cable

Input

1ch RCA (4ch optional)

1ch RCA (4ch optional)

4ch by RJ45(for IPC)

8ch by RJ45(for IPC)

Output

1ch RCA

Record & Playback

Video Compression

H.264

Audio Compression

G.711A

Image Encoding

Adjustable encoding quality, variable code stream/fixed code stream

Dual Stream

Support

Recording Mode

Manual, auto, motion detection, stop

Time bar

Support

Max Playback

IP : 1~2ch 720/1080P @ 25/30fps
     AHD / TVI / CVI : 1~4ch 1080N  @ 12fps

IP : 1~4ch 720/1080P  @ 25/30fps
     AHD / TVI / CVI : 1~8ch 1080N  @ 12fps

Backup Mode

USB,HDD,Network Backup,Mobile Harddisk

Video Detection&Alarm

Trigger Events

Recording, PTZ, Tour,Email

Motion Detection

396 (22×18) detection zone, variable sensitivity levels

Capture

JPEG capture

Alarm In/Output

4ch in,1ch out (Optional)

4ch in,1ch out (Optional)

Network

Ethernet

1 RJ-45 port (10M/100M)

P2P

Support

Cloud Storage

Support (Dropbox / Google Drive)

DDNS

Support Built-in Free DDNS

3G Dongle

Support

Network protocol

ONVF, TCP/IP, UDP, HTTP, RTP/RTSP

Network Functions

DHCP, PPPOE, DDNS,SMTP,SNTP,FTP,UPnP,P2P,3G

Remote Operation

Monitoring,PTZ control,playback,system setting,file download,log information

Smart Phone

iPhone,iPad,Android

Hard Disk

Hard Disk

1 SATA (Max: 8TB/HDD)

HDD Management

Hard disk hibernation technology, HDD faulty alarm&raid

General Details

USB Interface

2 USB 2.0 ports

RS485

PTZ control

Power Supply

DC 12V

Power Consumption

<9W (without HDD)

Working Environment

-10℃~+55℃  /  10%-90%RH

Dimension(W*D*H)

Machine: 255x215x42mm    Color Box:380x270x80mm

Weight

1.5 Kg (without HDD)

Installation

Desk type


Product Details


1. TVI / AHD / CVI / IPC / Analog 5 in 1.
2. Transmission distance up to 500M by coaxial cable 75-5(or above)
3. Support P2P
4. Support mobile surveillance
5. Support UTC function:Control AHD/TVI Camera & PTZ Dome camera via DVR by Coaxial Cable
6. Support Cloud Storage (Drop box / Google Drive)
7. Advanced time bar playback function can make playback exact to a second
8. Digital zoom function in both preview & playback
9. Support Built-in free DDNS
10. Support mobile hard disk backup
11. Support 3G wireless Dongle
12. Support Face Detection & Perimeter Detection (Optional)





Company Information



Why choose EOMonitoring?

1. EOMonitoring work as a professional P2P Network Video Recorder solution company with more than 5 years experience. We have more than 300 employees and 3 factories till 2017. We aim to offer you one-stop shopping experience of P2P Network Video Recorder product with good quality, competitive price and professional service.

2. We can offer various kinds of P2P Network Video Recorder product which is made of advanced mechanical equipment and experienced technical workers. We can make sure P2P Network Video Recorder on top quality and best price.

3. We can also offer P2P Network Video Recorder OEM and ODM Service. We can also offer different P2P Network Video Recorder solutions according to your needs and use.The P2P Network Video Recorder will be shipped from China factory directly to your warehouse or your home etc.

4. We can offer P2P Network Video Recorder free sample if you want test its quality. We are confident to be your best P2P Network Video Recorder supplier in China forever.

5. We take P2P Network Video Recorder attend many security professional exhibitions like CPSE in China,ISC West in Las Vegas, Securex in South Africa, IFSEC in London every year.


Our Service

If you have needs or doubts of our P2P Network Video Recorder product, please contact me freely based on above information,We will reply you soon within 24h. If you are urgent for P2P Network Video Recorder, please call me directly.
